NHP MOD6-3-40 Circuit Breaker 6kA 3 Pole 40A C Curve MOD6340

Rated current 40.0 A
Number of poles (total) 3.0
Trip curve C
Rated voltage 415.0 V
Frequency 50 - 60 Hz
Voltage type AC/DC
Rated short-circuit breaking capacity Icn
according to AS/NZS 60898 at 230 VAC 6.0 kA
Rated short-circuit breaking capacity Icn
according to AS/NZS 60898 at 400 VAC 6.0 kA
Max. rated operation voltage Ue 440.0 V
Rated insulation voltage Ui 440.0 V
Rated impulse withstand voltage Uimp 6.0 kV
CONSTRUCTION Number of protected poles 3.0
Degree of protection (IP) IP40
